| Material codes | B93 |
| Pressure | Up to 350 bar (5 075 psi) |
| Speed | Up to 0,5 m/s (1.6 ft/s) |
| Temperature range |  |
 |
Extreme low temperature range: may be intermittently exposed (e.g. cold start-up) without seal damage, but seal performance may be compromised while in this range |
 |
Temperatures below the recommended operating range: seal performance depends on system design (precision guiding arrangement recommended) |
 |
Recommended operating temperature range for this profile and material |
 |
Extreme high temperature range: only occasional short-term exposure (e.g. cylinder in curing oven of a powder coating process) |
| Dimension standards | Some sizes fit seal grooves in accordance with ISO 5597:2010. |
| Maximum values of application parameters (e.g. pressure, speed, temperature, e-gap) should not be applied continuously nor simultaneously. | |
